FORWARD - THREE-PHASE - ELEKTROVENT® Series

APPLICATIONS

These small centrifugal fans are suitable for conveying clean air and non-dusty fumes, up to a maximum temperature of 80°C*.

They are used in all industrial applications in which small volumes of air at medium-high pressure are required – for example, machine tools, suctioning or feeding into ducting, extractor hoods, etc.


CONSTRUCTION

Housing in painted steel plating. Simple suction impeller made of galvanised plate with forward curved blades. Asynchronous three- or single-phase motor, IP 55 protection level, class F insulation, efficiency 2, service S2, shape B35 (FORWAR D 122-142 shape B5 ), constructed according to IEC / EEC (UNEL MEC) standards, Version 5; direct coupling with projecting impeller rotation LG270.


TECHNICAL SPECIFICATIONS

Air conveyed: max 80°C.

Power voltage and frequency :

– single-phase (M) 230V-50 Hz

– three-phase (T) 400V-50 Hz

ON REQUEST

Support seat (excluded 122-142)



For the measurements see the dimensions attached

+ Show More

General catalogue - Find out more
Filters
FAET PART NUMBER DESCRIPTION
0412000 FORWARD 122M CENTRIF. FAN
0412001 FORWARD 142M CENTRIF. FAN
0412002 FORWARD 152M CENTRIF. FAN
0412003 FORWARD 162 M CENTRIF. FAN
0412004 FORWARD 182M CENTRIF. FAN
0412005 FORWARD 122T CENTRIF. FAN
0412006 FORWARD 142T CENTRIF. FAN
0412007 FORWARD 152T CENTIF. FAN
0412008 FORWARD 162T CENTRIF. FAN
0412009 FORWARD 182T CENTRIF. FAN
FORWARD MODEL PM (W) IN MAX (A) MOT (H) LP dB(A) PRICE EACH
90 0,29 56 60 558,90
180 0,65 63 68 660,68
250 1,35 71 70 733,13
550 1,9 80 71 910,80
1.100 2,5 80 74 1.062,98
122 T 90 0,29 56 60 541,65
142 T 180 0,65 63 68 660,68
152 T 250 1,35 71 70 721,05
1662 T 550 1,9 80 71 871,13
182 T 1.100 2,5 80 74 1.190,25
