TECHNICAL DETAILS

These are suitable for transferring liquids containing impurities of dimensions up to 2-3 mm. The hydraulic components: impeller, scroll and pump body in PBT, mean that is can be used with emulsions, and oily substances in general, with viscosity not exceeding 3° Engler (21° CST).

The temperature of the liquid must not exceed 70°C. They are ordinarily used on:

– Machine tools (milling machines – lathes – drills)

– Machines for glass work (TRI version)

– Printing machines (axle in aisi 420 – 304 – PBT on 270 mm dip tube.)

– Heating and air conditioning systems

– Filtration systems
