SA Series

GENERAL CHARACTERISTICS:

Designed for the circulation of refrigerant liquids in general, their main characteristic is the significant simplicity of construction. The external structure is made of thermoplastic material that is non-inflammable (VDE 0730 standard), the bearings are double shielded, the shaft is in stainless steel, and the pump body is watertight.


CONSTRUCTION DETAILS
:

  • Electric pump, specific for machine tools with immersed dip tube without seal rings.a
  • Single-phase shaded-pole motor
  • Windings in class “F”
  • Motor shaft in stainless steel AISI 303
  • SK long-life bearings
  • IP 54 grade protection against liquid penetration
  • All thermoplastic parts of the motor are non-flammable in compliance with standards VDE 0730 and UL 94

Notes and various warnings :

  • Motors with voltages and frequencies based on the client’s specific needs can be supplied
  • From three-phase lines, only two wires must be taken:

230 V three-phase line connecting 0 – 230

400V three-phase line connect 0 – 400

Packs: single items.

HYDRAULIC CHARACTERISTICS
